FIS-DNFS
FISolution
Non-woven Needle punched filter material is the fastest growing and most widely used filter material at present.
Needle felt filter material is a fibrous net with or without fabric on the two sides of the base cloth, which is made up of three dimensional interlaced fibers.Needle felt surface covered with a layer of PTFE micro porous membrane, influence can not only protect the filter from chemical corrosion and oil and water, but also can raise the accuracy of filtering bag.
Quality of the needle punched felt is stable and reliable, and the price is favorable. The needle felt produced in our factory can be accepted by the customers besides the industry standard model.
Filter media delivery programme
Synthetic needle felt with and without ePTFE membrane
Glass fibre fabric with ePTFE membrane
Working width up to 2.60 m
Basis weight from 250 to 950 g/m²
Designed as web material or slotted roll material
Core product catalogue for filter media with shortest delivery times
Custom-built and developed products at customer request
TYPES OF NON-woven NEEDLE PUNCHED FELTS
Quality of the needle punched felt is stable and reliable, and the price is favorable. The needle felt produced in our factory can be accepted by the customers besides the industry standard model.
Specifications: PPS needle felt, Acrylic Needle Felt, Middle temperature needle felt, PET antistatic felt, Homopolymer acrylic felt, P84 Needle Felt, PTFE Needle Felt, Aramid needle felt.
Fiber composition: PPS staple fiber,polyester staple fibre,Acrylic fiber,Aramid fiber,Conductive fiber.
Scrim Composition:Acrylic staple fiber,Aramid staple fiber,Polyester filament,glass fibre.
Filtration fibres and their interaction with different types of dust
Scrim and fibre types | Con. Temperature* (Peak) | Envirotec Designation | Hydrolysis-Resistance | Acid-Resistance | Alkali-Resistance | Oxidation-Resistance |
Polypropylene | 95 °C/(95 °C) | PP | excellent | excellent | excellent | moderate |
Polyamide | 110 °C/(115 °C) | PA | limited | moderate | good | moderate |
Polyacrylnitrile copolymer | 115 °C/(120 °C) | AC | good | moderate | good | good |
Temperatur-resistant olefin | 125 °C/(135 °C) | RO | excellent | excellent | excellent | moderate |
Polyacrylonitrile homopolymer | 125 °C/(140 °C) | DT | good | good | good | good |
Polyester | 150 °C/(150 °C) | PE | moderate | good | moderate | good |
Polyphenylene sulphide | 190 °C/(200 °C) | PPS | excellent | excellent | excellent | moderate |
M-Aramide | 200 °C/(220 °C) | NO, NX | moderate | moderate | moderate | good |
Polyimide | 240 °C/(260 °C) | PI | good | moderate | moderate | good |
Premium Fibre Blend | 240 °C/(260 °C) | PFB | good | Moderate | moderate | good |
Polytetrafluorethylene | 250 °C/(280 °C) | PTFE, TFL | excellent | excellent | excellent | excellent |
Fibreglass fabric | 260 °C/(288 °C) | GL | good | moderate | moderate | excellent |
PRODUCT PERFORMANCE
Needle felt surface covered with a layer of PTFE microporous membrane, influence can not only protect the filter from chemical corrosion and oil and water, but also can raise the precision of filtration bag, surface filtration mechanism, coated needle felt the total filtration efficiency can reach above 99.9999%.
Needle punched felts are widely used to eliminate dust pollution, improve environment, recycle materials and so on.
The dust removal efficiency is high, and the fine dust with particle size greater than 0.3 microns can be captured, and the dust removal efficiency can reach more than 99%;
Flexible use, the amount of air can be processed from hundreds of cubic meters per hour to hundreds of thousands of cubic meters per hour, can be directly located in the room, near the machine tool small units, can also be made into a large dust chamber, that is, "bag room".
The structure is relatively simple, the operation is relatively stable, the initial investment is less (compared with electrostatic precipitator), and maintenance is convenient.
NEEDLE PUNCHED FELTS PURPOSE
Needle punched felts are the key part in the operation process of the bag filter, and usually the cylindrical filter bag hangs vertically in the dust collector.
Heat-engine plant:Boiler,Calcium carbide furnace
Cement plant :Sinter Dust,Cement plant,Furnace Dust,Pneumatic conveying
Chemical industry :Filtered Dust, Flue Ash, Discharging Flue Ash, Coal Dust
Building material :Discharging Systems, Mixing Equipment, Homogenizing Systems, Warehouse Units,Asphalt concrete production line
Smelt/Steel-making: Aluminium electrolysis,Aluminum zinc smelting,
